Best China Side Wall Trailer Factory In Lowest Price 3 Axles 60 Tons With BV
| Model No. | TMA360TWT125FT |
| Axles Beam | HUAJIN China brand 13T*3 |
| Suspension | Mechanical,Option Air bag |
| Tires | 12.00R20, Radial 12+1 pcs Linglong brand |
| Brakes | Air brake with WABCO VALVE and ABS |
| Landing Gear | 38T*2 China brand |
| Kingpin | China brand 90# or 3.5" |
| Main Beam | Upper 14mm Middle 10 Lower 16mm |
| Side wall | 600/800 high,bottom 3mm side 1.5mm |
| Tool box | 1 set |
| Spare tire carrier | 1 set |
| Painting | 3 coats,any colors |
What is Side Wall Semi Trailer?
The Side wall semi-trailer is a semi-trailer with a railing structure. It has a wide range of uses, and is mainly suitable for medium and long-distance transportation of medium-heavy and bulk cargoes. It has strong applicability and has become the first choice for medium- and long-distance freight vehicles.
1. The vehicle body is made of high-quality steel, advanced technology and strict production. The vehicle structure is reasonable, the performance is reliable, the operation is simple, and the appearance is beautiful.
2. The series of semi-trailer frames are through-beam structure, and the longitudinal beam is straight or gooseneck. The web height is welded from 400mm to 550mm manganese plate. The longitudinal beam is welded by automatic submerged welding. The frame is shot blasted. The beam penetrates the longitudinal beam and is welded as a whole.
3. The suspension adopts non-independent steel plate stamped rigid suspension, which is made of tandem leaf springs and suspension bearings; the structure is reasonable, and it has strong rigidity and strength, which is used to support the load to reduce shock.
What is Side Wall Semi Trailers Advantages?
Compared with "monolithic" cars, semi-trailers can improve the overall economic benefits of road transport. Transport efficiency can be increased by 30-50%, costs can be reduced by 30-40%, and fuel consumption can be reduced by 20-30%. More importantly, the use of semi-trailers can also promote the organization of logistics in China to a certain extent.
